Specialising in Geotechnical Equipment Since 1990
Building Professionally Designed Quality / Bespoke / Customizable Drilling Equipment.
Compliance Certification available for different markets.
Designs based on a lifetime’s experience in the drilling and geotechnical industries.
BEDROCK compatible with BROKK
Aluminium Mast on a BROKK 90 with Safety Cage for specific Markets.
2.0M Overall length with 1.3M Stroke
Handheld CP 0069 fitted
Standard 50mm Rod Guide
Air Controlled manually by remote valve
Up/Down from BROKK Radio Unit
BEDROCK compatible with Kubota U17
Steel Mast on a Kubota U17-3a (1.7T)
Safety Cage for specific markets.
2.0M Overall length with 1.3M Stroke
Standard 50mm Rod Guide
Air Controlled manually on machine
Up/Down from auxiliary circuit
TopTec 5500 Remote Controlled
Built for HS2 Tunnels – Spiling
Steel Mast with hydraulic cage opening
Overall length 3M with 2.2M Stroke
Fully Remote Controlled
Hydraulic Clamp Single 25-70mm
Forklift compatible
“Y” axis articulation
Operating in the HS2 London Tunnels, this spiling setup features a 3M boom with a 2.2M stroke, hydraulically operated cage, and fully hydraulic drifter, all controlled remotely with robotic excavation and drilling equipment.
The BEDROCK HAVS BUSTER
(Hand-Arm-Vibration-Syndrome)
Here we have the solution the increasingly prevelent HAVS issue. At circa 50KG (without the drill), it is highly portable. Saddles available for all makes of handheld rock drills. Other uses: Rope Access Work.
Overall length 1.6M with 0.9M Stroke
BEDROCK compatible with Kobelco SK200
Anchoring at Contiguous Piles
Fully Radio Remote Controlled
Steel Mast – 4M long – 3.2M Stroke
Full-length Hydraulic Safety Cage
Forklift Compatible in laydown
Hydraulic Clamp 25-70mm
4Way Cradle & “Y” Axis Slew
BEDROCK compatible with Hitachi 130
Built for DTH Rock Anchoring
Fully Radio Remote Controlled
Steel Mast – 4M long – 3.2M Stroke
Full-length Hydraulic Safety Cage
Forklift Compatible in laydown
100mm Split Rod Guide &
Interlocking Spanner for 4” DTH
4 Way Cradle & “Y” Axis Slew
BEDROCK suitable for Solar Farm
Built for DTH Post Drilling
Fully Radio Remote Controlled
Steel Mast – 4M long – 3.2M Stroke
Vertical Compliant Safety Cage
Forklift Compatible in laydown
100mm Split Rod Guide &
Interlocking Spanner for 4” DTH
4 Way Cradle & “Y” Axis Slew
BEDROCK compatible with BOBCAT
Soil Nailing – Low Cost Solution
Overall length 4M with 3.2M Stroke
Hydraulic Clamp 25-70mm
Manual Spool Valve Chest (portable)
Extremely Robust & Versatile
Safety Lifeline Estop available
BEDROCK compatible with Stanley SK 58
Base Level Hydraulic Drifter
